Fire-resistant EMC Marine Power and Control Cable
The cable is intended for power, lighting and control system of shipboard and off-shore building.
Specification & Standards:
IEC 60288 IEC60092-376 IEC60092-351 IEC60092-359
IEC61034 IEC 60754
1. Conductor: tinned copper
2. Insulation: EPR/XLPE
3. Core screen: Tinned copper wire braid
5. Inner sheath: PCP/CSP/PVC/PO (SHF1, SHF2)
6. Armored: tinned copper wire braid
(Galvanized steel wire braid)
7. Outer sheath: PVC/PO (SHF1, SHF2)
DA: Single cable flame retardant
SA: Bunched cable flame retardant
SC: Bunched cable flame retardant,halogen-free, low-smoke, low-toxicity.
Cores: 1, 2, 3, 4, 5, 7, 10, 12, 14, 16,19, 24, 27, 30, 33, 37.
Nominal Cross-section Areas:
